2.5.4 LD0.SRGAPC1 Reset SRGAPC1 generic flip-flops
Table 147: LD0.SRGAPC1 Reset SRGAPC1 generic flip-flops
0xA CS IEC 61850 name SA name Description Values
LD0.SRGAPC1
2096 4.00 .Rs1.Oper.ctlVal Reset flip-flop 1 1=Reset
2097 4.01 .Rs2.Oper.ctlVal Reset flip-flop 2 1=Reset
2098 4.02 .Rs3.Oper.ctlVal Reset flip-flop 3 1=Reset
2099 4.03 .Rs4.Oper.ctlVal Reset flip-flop 4 1=Reset
2100 4.04 .Rs5.Oper.ctlVal Reset flip-flop 5 1=Reset
2101 4.05 .Rs6.Oper.ctlVal Reset flip-flop 6 1=Reset
2102 4.06 .Rs7.Oper.ctlVal Reset flip-flop 7 1=Reset
2103 4.07 .Rs8.Oper.ctlVal Reset flip-flop 8 1=Reset
2.5.5 LD0.SRGAPC2 Reset SRGAPC2 generic flip-flops
Table 148: LD0.SRGAPC2 Reset SRGAPC2 generic flip-flops
0xA CS IEC 61850 name SA name Description Values
LD0.SRGAPC2
2104 4.08 .Rs1.Oper.ctlVal Reset flip-flop 1 1=Reset
2105 4.09 .Rs2.Oper.ctlVal Reset flip-flop 2 1=Reset
2106 4.10 .Rs3.Oper.ctlVal Reset flip-flop 3 1=Reset
2107 4.11 .Rs4.Oper.ctlVal Reset flip-flop 4 1=Reset
2108 4.12 .Rs5.Oper.ctlVal Reset flip-flop 5 1=Reset
2109 4.13 .Rs6.Oper.ctlVal Reset flip-flop 6 1=Reset
2110 4.14 .Rs7.Oper.ctlVal Reset flip-flop 7 1=Reset
2111 4.15 .Rs8.Oper.ctlVal Reset flip-flop 8 1=Reset
2.5.6 LD0.SPCGGIO1 Multipurpose binary outputs (1)
The binary outputs can be configured either as pulse- or persistent-type outputs. Pulse-
type outputs are triggered with the write value "1". Persistent-type outputs can be
written with both values "1" and "0". The setting mode "toggled" for local
operation corresponds to "persistent" for remote operation.
Table 149: LD0.SPCGGIO1 Multipurpose binary outputs (1)
0xA
CS IEC 61850 name SA name Description Values
LD0.SPCGGIO1
2112 5.00 .SPCS01.ctlVal Output 1 control 0/1=Off/On
2113 5.01 .SPCS02.ctlVal Output 2 control 0/1=Off/On
2114 5.02 .SPCS03.ctlVal Output 3 control 0/1=Off/On
Table continues on next page
Section 2 1MRS757822 B
Modbus data mappings
80 Recloser Protection and Control RER615
Point List Manual
