2.3.30 LD0.PHPTOV1 Phase overvoltage protection (1)
Table 33: LD0.PHPTOV1 Phase overvoltage protection (1)
BitA RegA IEC 61850 name SA name Description Values
LD0.PHPTOV1
3088 193.00 .Str.general START General start 1=Start
3089 193.01 .mcd
3090 193.02 .Str.phsA phsA start 1=Start
3091 193.03 .mcd
3092 193.04 .Str.phsB phsB start 1=Start
3093 193.05 .mcd
3094 193.06 .Str.phsC phsC start 1=Start
3095 193.07 .mcd
3096 193.08 .Op.general OPERATE General operate 1=Operate
3097 193.09 .mcd
2.3.31 LD0.PHPTOV2 Phase overvoltage protection (2)
Table 34: LD0.PHPTOV2 Phase overvoltage protection (2)
BitA
RegA IEC 61850 name SA name Description Values
LD0.PHPTOV2
3098 193.10 .Str.general START General start 1=Start
3099 193.11 .mcd
3100 193.12 .Str.phsA phsA start 1=Start
3101 193.13 .mcd
3102 193.14 .Str.phsB phsB start 1=Start
3103 193.15 .mcd
3104 194.00 .Str.phsC phsC start 1=Start
3105 194.01 .mcd
3106 194.02 .Op.general OPERATE General operate 1=Operate
3107 194.03 .mcd
2.3.32 LD0.PHPTOV3 Phase overvoltage protection (3)
Table 35: LD0.PHPTOV3 Phase overvoltage protection (3)
BitA
RegA IEC 61850 name SA name Description Values
LD0.PHPTOV3
3108 194.04 .Str.general START General start 1=Start
3109 194.05 .mcd
3110 194.06 .Str.phsA phsA start 1=Start
Table continues on next page
Section 2 1MRS757822 B
Modbus data mappings
