KNX control elements and application parameters
"Switch" control element
Product manual 2CKA001473B5343
117
– Pressing/releasing: Pressing = value 1; releasing = value 2.
The following supplementary parameters are available, see chapter “Object type 1 / value 2“
on page 117:
– Object type value 1: When actuated (pressing) the control element sends telegrams via
the associated communication object. This parameter is used to specify the size of the
communication object.
– Object type value 2: When actuated (releasing) the control element sends telegrams via
the associated communication object. This parameter is used to specify the size of the
communication object.
– Short/long: Short press = value 1; long press = value 2.
The following supplementary parameters are available, see chapter “Object type 1 / value 2“
on page 117:
– Long operation after...:
Options: Setting option from 0.3 - 10 seconds
The parameter is used to specify how long the button must be pressed to recognize a
long operation.
– Object type value 1: When actuated (short press) the control element sends telegrams
via the associated communication object. This parameter is used to specify the size of
the communication object.
– Object type value 2: When actuated (long press) the control element sends telegrams
via the associated communication object. This parameter is used to specify the size of
the communication object.
10.1.6 Object type 1 / value 2
Options: Inactiv
Switch
Forced operation
1-byte value [0% - 100%]
1-byte value [0 - 255]
1-byte value [-128 - 127]
Scene number
RTC operating mode
Temperature
2-byte value [-32768 - +32767]
2-byte value [0 - 65535]
2-byte floating point
4-byte value [-2147483648 - 2147483647]
4-byte value [0 - 4294967295]
14-byte text
Parameters "Object type value 1" and "Object type value 2" are used to specify the size of the
communication object.
Notice
The parameters are only available when parameter "Type of switching" is set on
"Pressing/releasing" or "Short/long".
