KNX control elements and application parameters
Control element "Audio control"
Product manual 2CKA001473B5343
192
– Deactivated: No forward/reverse control is enabled. No additional parameters available.
– Activated: Forward/reverse control is enabled. The following supplementary parameter is
available:
10.14.8 Object type Forward/reverse control
Notice
"Forward/Reverse control" object type is only available if "Use
Forward/Reverse control" is activated.
Object type Forward/reverse control:
Options: 1 bit
1-byte value [0 - 255]
The parameter is used to specify the size of the communication object for sending
telegrams.
- 1 bit: Commands for "Forward" are sent with 1 bit (0 or 1). The following supplementary
parameter is available:
Value for forward:
Options: 0
1
The parameter is used to send the command for "Forward" with "0" or "1".
- 1 bit: Commands for "Return" are sent with 1 bit (0 or 1). The following supplementary
parameter is available:
Value for return:
Options: 0
1
The parameter is used to send the command for "Return" with "0" or "1".
- 1-byte value [0 - 255]: The value for "Forward" is sent as a 1-byte unsigned value. The
following supplementary parameter is available:
Value for forward:
Options: Setting option from 0 - 255
The parameter is used to send the value for "Forward" as absolute value.
- 1-byte value [0 - 255]: The value for "Return" is sent as a 1-byte unsigned value. The
following supplementary parameter is available:
Value for return:
Options: Setting option from 0 - 255
The parameter is used to send the value for "Return" as absolute value.
10.14.9 Use of button for mute
