Commissioning via ABB-free@home®
Product manual 2CKA001473B5343
49
8.1.1 Add device
1. Tap on the switch icon (menu devices, scenes and groups) at the left edge of the screen.
– The "Building plan" opens.
2. Tap on the round plus icon at the bottom right [1].
– Menu "Select component" opens.
Fig. 23: Opening the building plan and list of components (example illustration)
3. Tap on the desired characteristic in the list of components.
– The menu with the available devices, functions and actuators opens.
4. Select the desired device and pull it into the floor plan via drag-and-drop.
Fig. 24: Pulling the device out of the menu bar (example illustration)
If you pull a new device into a room via drag and drop, a pop-up window opens in which all
devices that are located in the system are listed and which have not been allocated to a room.
The devices are suitable respectively for the selected application.
