6.5.5 Mounting with surface-mounted mounting frame
First, depending on the mounting version according to the following specification, the surface-
mounted mounting frame must be installed:
Fig. 10: Installation of surface-mounted mounting frame
Notice
For additional information see the enclosed mounting instructions for surface-
mounted mounting frames.
Continue with “Electrical connection“ on page 40 and “Installation“ on page 41.
Mounting with table stand
Fig. 11: Table stand 83506-500
Continue with “Electrical connection“ on page 40 and “Installation“ on page 41.
