KNX control elements and application parameters
Control element "Audio control"
Product manual 2CKA001473B5343
195
The parameter is used to send the the "Value for repeating" with "0" or "1".
- 1 bit: Repeat commands are sent with 1 bit (0 or 1). The following supplementary
parameter is available:
Value for not repeating:
Options: 0
1
The parameter is used to send the the "Value for not repeating" with "0" or "1".
- 1-byte value [0..255]: The value of the repetition is sent as a 1-byte unsigned value. The
following supplementary parameter is available:
Value for repeating:
Options: Setting option from 0 - 255
The parameter is used to send the "Value for repeating" as absolute value.
- 1-byte value [0 - 255]: The value of the repetition is sent as a 1-byte unsigned value.
The following supplementary parameter is available:
Value for not repeating:
Options: Setting option from 0 - 255
The parameter is used to send the "Value for not repeating" as absolute value.
10.14.3 Use of volume button
Options: Deactivated
Activated
– Deactivated: No volume button is enabled. No additional parameters available.
– Activated: The volume button is enabled. The following supplementary parameter is
available:
Object type volume button:
Options: 2 x 1 Bit
1 x 4 Bit
1-byte value [0 - 100%]
The parameter is used to specify the size of the communication object for sending
telegrams.
– 2 x 1 bit: Commands of a volume button are sent with 2 x 1 bit (0 or 1). The following
supplementary parameters are available:
Value for increase:
Options: 0
1
The parameter is used to send the command for "Increase volume" with "0" or "1".
Value for decrease:
Options: 0
1
