KNX control elements and application parameters
"Display" control element
Product manual 2CKA001473B5343
174
– 1-byte value [0 - 255]: A status value is sent as 1-byte value without a sign. The following
supplementary parameters are available:
Text x for value [0 - 255]:
Options: Setting option from 0 - 255
The parameter is used to set the status value at which text x is displayed.
Notice
8 parameters of "Text x at value [0 - 255]" are available which can be set as
required.
Text x:
Options: <Text>
The parameter is used to specify the text that is displayed.
The length of the text is limited to 60 characters.
Notice
8 parameters of "Text x" are available which can be set as required.
10.13.7 Type of display element — Value display — Measurement display with colour display
Options: Deactivated
Activated
The parameter is used to specify whether a colour display follows.
For this the communication object is enabled.
– Switching red
– Switching orange
– Switching green
