KNX control elements and application parameters
Control element "Rocker switch"
Product manual 2CKA001473B5343
124
10.2.8 Object type
Options: Switch
Forced operation
1-byte value [0% - 100%]
1-byte value [0 - 255]
1-byte value [-128 - 127]
Scene number
RTC operating mode
Temperature
2-byte value [-32768 - +32767]
2-byte value [0 - 65535]
2-byte floating point
4-byte value [-2147483648 - 2147483647]
4-byte value [0 - 4294967295]
14-byte text
When actuated, the control element sends telegrams via the associated communication object.
Parameter "Object type" is used to specify the size of the communication object.
Notice
Value 1 is assigned to the left button, and value 2 to the right button.
– Switch: The following supplementary parameter is available:
Sent value 1 / value 2:
Options: 0
1
– 0 / 1: Switching commands are sent with 1 bit (0 or 1), e.g. for switching a switching
actuator.
– Forced operation: Management systems can access the device directly via KNX. It can
additionally be specified that selection can be carried out manually via buttons (forced
operation). The following supplementary parameter is available:
Sent value 1 / value 2:
Options: ON, forced operation active
OFF, forced operation active
Deactivate forced operation
