ABB SmartTouch B/stainless User Manual

Connection, installation / mounting
Product manual 2CKA001473B5343
│
38
6.5.4 Mounting in flush-mounted installation box in hollow wall
Installation on the basis of the instructions on the enclosed drilling template:
Notice
See mounting instructions on the enclosed plaster and drilling template.
The bottom part of the flush-mounted installation box is not required here.
1
2
3 4
Fig. 9: Mounting in hollow wall
Continue with “Electrical connection“ on page 40 and “Installation“ on page 41.

ABB SmartTouch B/stainless Specifications

General

Display Resolution	800 x 480 pixels
Mounting	Wall or panel mounting
Material	Stainless Steel
Operating Temperature	-10°C to +50°C
Display Size	7 inches
Resolution	800 x 480 pixels
Protection Rating	IP65
Communication Interface	Ethernet
Protection	IP65 (front)
