Commissioning of the KNX function via ABB DCA SmartTouch 10 (from
ETS5)
Product manual 2CKA001473B5343
112
This application has no application page. The internal room temperature controller (RTC) can
be controlled via the "RTC control element" (extension unit). For this the control element must
be allocated accordingly and equipped with group addresses.
The general settings can be made via the DCA as follows:
1. Open the "Applications" tab in the library area.
2. Open the "Internal RTC".
– The general settings for this application are displayed in the "Parameter" area and can
be edited here.
Notice
Individual internal RTCs can be created. These can also be added via the work
area.
■
Here a page with a plus is displayed. This page must be clicked. This is how
a further internal RTC is added and displayed in the tree structure.
■
If it is called up via the tree structure, the settings can be adjusted for the
individual internal RTCs in the "Parameter" area.
■
By clicking the arrow next to "Internal RTC", all available internal RTCs are
displayed.
For further setting or selection options via the "Parameter" area for the general settings of the
function of the internal RTC, see chapter 9.10.7 “Application "Internal RTC"“ on page 109.
9.12 Editing group addresses
Group addresses are created and managed in the "Group addresses" area.
Notice
Detailed expert knowledge for understanding by means of KNX training is
assumed, especially with regard to the commissioning software ETS.
