KNX control elements and application parameters
Application "Internal RTC"
Product manual 2CKA001473B5343
278
10.24.145 Fan speeds/- levels
10.24.146 Fan speeds/- levels heating
Notice
Only available when parameter "Number of fans" is set on "Heating/cooling via
two systems".
10.24.147 Fan speeds/- levels cooling
Notice
Only available when parameter "Number of fans" is set on "Heating/cooling via
two systems".
10.24.148 Fan speeds/- levels - Number of fan speeds/- levels
Options: 3 levels
5 levels
10 levels (output 0-255)
This parameter is used to specify the number of fan speed levels the actuator will use to control
the fan of the fan coil.
10.24.149 Fan speeds/- levels - Format of speeds-/ level output
Options: 0-5
0-255
1 bit m off n
1 bit m 1 off n
– 0-5: The level values (0-3 or 0-5) are output in the 1 byte format as counter values 0-3 or 0-
5.
– 0-255: The level values (0-3 or 0-5) are output as percentage values. Example 5-stage fan:
The level value 1 is output as 20%, and 5 is output as 100%.
– 1 Bit 1 from n: The level values (0-3 or 0-5) are output using 1-bit objects. The number of
objects available is the same as the number of fan speed levels. For level 2, for example,
the 1-bit fan speed level objects 1 and 2 are output as the value 1, while the other fan speed
level objects use the value 0.
– 1 Bit 1 from n: The level values (0-3 or 0-5) are output using 1-bit objects. The number of
objects available is the same as the number of fan speed levels. For the level 2, for
example, only the 1-bit fan speed level object 2 is output as the value 1. The other fan
speed level objects use the value 0.
10.24.150 Fan speeds/- levels - Speeds-/ levels output
