ABB SmartTouch B/stainless

KNX communication objects
Application "Internal RTC"
Product manual 2CKA001473B5343
│
282
Mute incoming calls Input/
Output
1 bit [1.001]
Switching
K - S U A
Switch Light Input 1 bit
[1.001]
Switching
K - S U A
Open door Input 1 bit [1.001]
Switching
K - S U A
Control element 1 Output 1 bit [1.001]
Switching
K - - U -
Control element 2 Output 1 bit
[1.001]
Switching
K - - U -
Control element 3 Output 1 bit [1.001]
Switching
K - - U -
Control element 4 Output 1 bit [1.001]
Switching
K - - U -
Control element 5 Output 1 bit [1.001]
Switching
K - - U -
Inputs
Binary input Output 1 bit [1.001]
Switching
K - - U -
Temperature sensor Output 2
bytes
[9.001]
Temperatur
e
(°C)
K - - U -
Name
Object
function
Lengt
h
Data type Flags
K L S U A
Fault and alarm messages
Signal tone volume Input 1 byte
[5.001]
Percent
(0 - 100%)
K - S - A
Raise/lower signal tone
volume
Input 1 byte
[3.007]
Dimmer
step
K - S - A
Confirm all [1 bit] Input 1 bit [1.016]
Confirmatio
n
K - S - A
Message [14 bytes] Input/
Output
14
bytes
[16.001]
Character
(ISO 8859-
1)
K - S U A
Message [1bit] Input/
Output
1 bit [1.005]
Alarm
K - S U A
Confirm message
[14 bytes]
Output 14
bytes
[16.001]
Character
(ISO 8859-
1)
K - S U A
Confirm message
[1bit]
Input/
Output
1 bit [1.016]
Confirmatio
n
K - S U A
Scene actuator
Object 1 [send] Output 1 bit [1.001]
Switching
K - - U -
Object 1 [receive] Input 1 bit
[1.001]
K - S U A
