ABB SmartTouch B/stainless

KNX communication objects
Application "Internal RTC"
Product manual 2CKA001473B5343
│
292
Name Object
function
Lengt
h
Data type Flags
K L S U A
Economy cooling setpoint Input 2
bytes
[9.001]
Temperatur
e
(°C)
K - S - A
Cooling setpoint for
building protection
Input 2
bytes
[9.001]
Temperatur
e
(°C)
K - S - A
Setpoint error Output 1 bit [9.001]
Temperatur
e
(°C)
K - - U -
Current HVAC operating
mode
Output 1 byte
[20.102]
HVAC
mode
K - S U A
Switch
Value 1 [send] Input/
Output
1 bit [1.001]
Switching
K - S U A
Value 2 [send] Output 1 bit [1.001]
Switching
K - - U -
Status value [receive] Input 1 bit [1.001]
Switching
K - S - A
Block Input 1 bit [1.002]
Boolean
K - S - A
Rocker switch
Value 1 [send] Input/
Output
1 bit [1.001]
Switching
K - S U A
Value 2 [send] Output 1 bit [1.001]
Switching
K - - U -
Status value [receive] Input 1 bit [1.001]
Switching
K - S - A
Block Input 1 bit [1.002]
Boolean
K - S - A
Dimmer
Switch
Input/
Output
1 bit
[1.001]
Switching
K - S U A
Dimming Output 3 bit [3.007]
Dimmer
step
K - S U -
Value Input/
Output
1 byte [5.001]
Percent
(0 - 100%)
K - S U A
Switch status Input 1 bit [1.001]
Switching
K - S - A
Status value Input 1 byte [5.001]
Percent
(0 - 100%)
K - S - A
Block Input 1 bit [1.002]
Boolean
K - S - A
Dimmer slider
Switch Input/ 1 bit [1.001] K - S U A
