ABB SmartTouch B/stainless

KNX communication objects
Application "Internal RTC"
Product manual 2CKA001473B5343
│
295
Name Object
function
Lengt
h
Data type F
l
a
g
s
K L S U A
HSV value [3 bytes] Output 3
bytes
[232.600]
RGB value
3x
(0 - 255)
K - - U -
Status value RGB [3
bytes]
Input 3
bytes
[232.600]
RGB value
3x
(0 - 255)
K - S - A
Brightness value Output 1 byte [5.010]
Counting
pulses
(0 - 255)
K - - U -
Brightness status value Input 1 byte [5.010]
Counting
pulses
(0 - 255)
K - S - A
Temperature value Output 2
bytes
[7.600]
Absolute
colour
temperatur
e (K)
K - - U -
Temperature status value Input 2
bytes
[7.600]
Absolute
colour
temperatur
e (K)
K - S - A
Blind
Moving UP/DOWN Input/
Output
1 bit [1.008]
Up/Down
K - S U A
Stop / slat adjustment Input/
Output
1 bit [1.008]
Up/Down
K - S U A
Move to position Input/
Output
1 byte [5.001]
Percent
(0 - 100%)
K - S U A
Slat position Input/
Output
1 byte [5.001]
Percent
(0 - 100%)
K - S U A
Position status Input 1 bit
[1.002]
Boolean
K - S - A
Upper end position status Input 1 bit [1.002]
Boolean
K - S - A
Bottom end position
status
Input 1 bit [1.002]
Boolean
K - S - A
Height status [0 - 100%] Input 1 byte [5.001]
Percent
(0 - 100%)
K - S - A
Slat status [0-100%] Input 1 byte
[5.001]
Percent
(0 - 100%)
K - S - A
Height status [0 - 255] Input 1 byte [5.010]
Counting
pulses
K - S - A
