ABB SmartTouch B/stainless

KNX communication objects
Application "Internal RTC"
Product manual 2CKA001473B5343
│
297
(slave)
Heating/Co
oling
Request fan speed level
manually (slave)
Output 1 bit [1.001]
Switching
K - - U -
Request fan speed level
(slave)
Output 1 byte [6.010]
Counting
pulses
(-128 - 127)
K - - U -
Confirm fan speed level
(slave)
Input/
Output
1 byte
[6.010]
Counting
pulses
(-128 - 127)
K - S U A
Name Object
function
Lengt
h
Data type Flags
K L S U A
Block Input 1 bit [1.002]
Boolean
K - S - A
Fan switch
Step output Input/
Output
1 byte [5.100}
Fan speed
level
(0 - 255)
K - S U A
Status output steps Input 1 byte [5.100}
Fan speed
level
(0 - 255)
K - S - A
Output 1 Input/
Output
1 bit [1.002]
Boolean
K - S U A
Output 2
Input/
Output
1 bit
[1.002]
Boolean
K - S U A
Output 3 Input/
Output
1 bit [1.002]
Boolean
K - S U A
Output 4 Input/
Output
1 bit [1.002]
Boolean
K - S U A
Output 5
Input/
Output
1 bit
[1.002]
Boolean
K - S U A
Output 6 Input/
Output
1 bit [1.002]
Boolean
K - S U A
Output 7 Input/
Output
1 bit [1.002]
Boolean
K - S U A
Output 8 Input/
Output
1 bit [1.002]
Boolean
K - S U A
Block Input 1 bit [1.002]
Boolean
K - S - A
Split Unit Control
Control On/Off Input/
Output
1 bit [1.001]
Switching
K - S U A
Setpoint temp
Input/
Output
2
bytes
[9.001]
Temperatur
e
(°C)
K - - U -
Actual temperature Input 2
bytes
[9.001]
Temperatur
e
K - S U A
