Abov MC96F6332D - IE2 (Interrupt Enable Register 2); IE3 (Interrupt Enable Register 3)

MC96F6432
106 June 22, 2018 Ver. 2.9
IE2 (Interrupt Enable Register 2) : AAH
7
6
5
4
3
2
1
0
–-
–
INT17E
INT16E
INT15E
INT14E
INT13E
INT12E
–
–
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
INT17E
Enable or Disable Timer 4 Interrupt
0
Disable
1
Enable
INT16E
Enable or Disable Timer 3 Match Interrupt
0
Disable
1
Enable
INT15E
Enable or Disable Timer 2 Match Interrupt
0
Disable
1
Enable
INT14E
Enable or Disable Timer 1 Match Interrupt
0
Disable
1
Enable
INT13E
Enable or Disable Timer 0 Match interrupt
0
Disable
1
Enable
INT12E
Enable or Disable Timer 0 Overflow Interrupt
0
Disable
1
Enable
IE3 (Interrupt Enable Register 3) : ABH
7
6
5
4
3
2
1
0
–
–
–
INT22E
INT21E
INT20E
INT19E
INT18E
–
–
–
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
INT22E
Enable or Disable BIT Interrupt
0
Disable
1
Enable
INT21E
Enable or Disable WDT Interrupt
0
Disable
1
Enable
INT20E
Enable or Disable WT Interrupt
0
Disable
1
Enable
INT19E
Enable or Disable SPI 2 Interrupt
0
Disable
1
Enable
INT18E
Enable or Disable ADC Interrupt
0
Disable
1
Enable
