Abov MC96F6332D - Page 88

MC96F6432
88 June 22, 2018 Ver. 2.9
P2FSRH (Port 2 Function Selection High Register) : D7H
7
6
5
4
3
2
1
0
–
–
–
–
P2FSRH3
P2FSRH2
P2FSRH1
P2FSRH0
–
–
–
–
R/W
R/W
R/W
R/W
Initial value : 00H
P2FSRH3
P27 Function select
0
I/O Port
1
SEG6 Function
P2FSRH2
P26 Function Select
0
I/O Port
1
SEG7 Function
P2FSRH1
P25 Function select
0
I/O Port
1
SEG8 Function
P2FSRH0
P24 Function Select
0
I/O Port
1
SEG9 Function
