MNR-310 System Administrator’s Manual
24
GPS Module Installation (Optional)
For your standalone NVR, you may have purchased the additional GPS module that can
provide your NVR with GPS data. When installing, please make sure your device is turned off,
and follow the steps below:
Step 1: Remove the MNR’s chassis cover
Loosen and remove the six screws on the top cover. Lift up the cover to reveal the main board.
Step 2: Prepare all parts provided for your GPS module
Step 3: Find the location for your GPS module
GPS Module x 1
Module Connector x 1
GPS Antenna x 1
RF Cable x 1
2 Rings (1 Hexagonal, 1 Circular)
2 Mounting Screws
To Next Page
