ADT-HC4500 Flame/Plasma Cutting Machine CNC System
- 101 -
0005: M02
3.10. G91/G90 relative/absolute coordinate programming
Relative coordinates under G91 (default), absolute coordinates under G90
Format: G91
G01 X100
---
3.11. G41/G42/G40
Set the slot compensation, which is set before steel plate perforating and cutting, and canceled by M08 instruction
Programming format:
G41 Left compensation
G42 Right compensation
G40 Cancel compensation
4. Common M instructions
1) Commonest M instructions:
The user only needs to be familiar with the function of M07, M08 and M02. M07 is the fixed cycle of preheating
perforating; after track processing and executing M08, the system will turn off related air valve, and M02
processing ends finally. The specific code functions follow
M07 p Fixed cycle of preheating perforating; the operation procedure follows:
Flame:
1. Ethyne valve open M10;
2. Ignition open M20;
3. Torch down M16;
4. Preheating valve opens, starts preheating M24;
5. Perforating torch up M14;
6. Cutting oxygen valve open M12;
7. Perforating torch down M16;
8. Perforating action completes, performs next action
Plasma:
A. When height adjustment system is on:
1. Enable height adjustment (corner) M22
