ADT-HC4500 Flame/Plasma Cutting Machine CNC System
- 133 -
Appendix 4: M Instruction Fact Sheet
S/N Instruction name Description
1 M02 Program ends
2 M07 Start fixed cycle of preheating perforating
3 M08 Turn off the fixed cycle of cutting oxygen (plasma arc)
4 M10/M11 Ethyne valve switch, M10 (ON), M11 (OFF)
5 M12/M13
Cutting oxygen valve switch (plasma arc switch), M12 (ON), M13
(OFF)
6 M14/M15 Torch up switch, M14 (ON), M15 (OFF)
7 M20/M21 Ignition switch, M20 (ON), M21 (OFF)
8 M24/M25 Preheating oxygen valve switch, M24 (ON), M25 (OFF)
9 M52 Fixed ignition cycle (controlled by time in “Control” interface)
10 M70 Fixed torch up cycle (controlled by time in “Control” interface)
11 M71 Fixed torch down cycle (controlled by time in “Control” interface)
12 M72
Fixed perforating torch up cycle (controlled by time in “Control”
interface)
13 M73
Fixed perforating torch down cycle (controlled by time in “Control”
interface)
14 M74 Fixed preheating cycle (controlled by time in “Control” interface)
15 M16 Torch down switch, M16 (ON), M17 (OFF)
16 M80 General switch,; all outputs will be turned off after performing M80
