ADT-HC4500 Flame/Plasma Cutting Machine CNC System
- 132 -
Appendix 3: G Instruction Fact Sheet
S/N Instruction name Description
1 G00 Quick positioning (run idle)
2 G01 Linear processing
3 G02 Clockwise circle processing
4 G03 Counterclockwise circle processing
5 G04 Pause/delay
6 G26 X axis returns to reference point
7 G27 Y axis returns to reference point
8 G28 Both X axis and Y axis return to reference point
9 G22 Cycle starts (must be used together with G80)
10 G80 Cycle ends (must be used together with G80)
11 G81 Counting function
12 G40 Cancel slot compensation
13 G41 Left compensation
14 G42 Right compensation
15 G92 Processing reference point setting
