ADT-HC4500 Flame/Plasma Cutting Machine CNC System
- 106 -
󰫥󰃌󳔈 Digital input
USB 󳖏󳄤 USB communication / Serial port
2.2 Electrical specifications
Switching quantity input
Channel: 32, all optic coupling isolation
Input voltage: 12-24V DC
High level>4.5V
Low level<1.0V
Isolation voltage: 2500V DC
Count input:
Channel: main axis ABZ phase code input, all optic coupling isolation
Maximum counting frequency: 2MHz
Input voltage: 5-24V DC
High level >4.5V
Low level <1.0V
Isolation voltage: 2500V DC
Pulse output:
Channel: 3 pulses, 3 directions, all optic coupling isolation
Maximum pulse frequency: 2MHz
Output type: 5V differential output
Output mode: pulse + direction or pulse + pulse
Switching quantity output:
Output Channel: 16, all optic coupling isolation
Output type: NPN collector open-circuit, 12-24V DC, maximum current: 100mA
RS-232 baud rate (bps):
1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200
