ADT-HC4500 Flame/Plasma Cutting Machine CNC System
- 73 -
Slot
compensation
Flame/plasma radius compensation mm
Preheating up
delay
(Plasma) Torch up time while perforating delay 0.01 sec
Corner speed
ratio
(Plasma) When the processing speed percentage drops to
this value, height adjustment control signal is turned off;
when the processing speed percentage rises to this value,
height adjustment control signal is turned on
%
Corner arc
radius
(Plasma) Set the critical value of arc radius when
processing arc
The speed drops if the arc radius is smaller than this value
mm
Corner down
speed
(Plasma) Set the speed dropping to this percentage if the
radius is smaller than corner arc radius when processing
arc
Speed = F × Processing speed percentage × corner
descending speed
%
Table 4.4
4.5 Precision
In Fig. 4 system parameter setting interface, press [F5] to show the interface below, in which you can set the
distance (mm) of X, Y axis moving every pulse. The value affects the precision of the track directly.
