ADT-HC4500 Flame/Plasma Cutting Machine CNC System
- 17 -
data are adjusted according to field cutting effect:
Processing speed (mm/min) Start speed (mm/min)
100-200 100
200-500 200
500-700 300
700-800 500
800-1000 600
1000-1300 700
1600-2000 1000
2000-3000 1500
3000-4000 2000
Table 2.8.1
2. Acceleration: the average increment that the processing speed is added from start speed to top speed;
for example: if the start speed is 300, the acceleration is 100 and the top processing speed is 1000, then the
processing speeds are 300, 400, 500…1000, added to top speed by 100.
The acceleration value is affected by Pulse Equivalent (in the main menu interface, press [F4] (Parameter)
[F5] (Precision)).
Pulse equivalent: the distance that the machine tool moves every time the control system sends a pulse
The followings are the pulse equivalent and acceleration for reference, and the actual data are adjusted
according to field cutting effect:
Pulse equivalent Acceleration (mm/min)
0.001000-0.002000 10
0.002000-0.003000 20
0.003000-0.004000 30
0.004000-0.005000 40
0.005000-0.006000 50
0.006000-0.007000 60
0.007000-0.008000 70
0.008000-0.009000 80
0.009000-0.010000 90
