(5) Set the frequency reference
You have shifted to Parameters mode
-Press the SELECT key (right key) once
The Display group of Parameters mode is emerged.
Move to 22 group
-Press the SELECT key (right key) once
The sub menu of Display group mode is emerged
Set the value and press the SAVE key (right key)
