 10.27 DO1 (RN0-RN1) ON delay time
Range: 0.0 ~ 3000 Sec in 0.1 Sec
Initial value: 0.0 Sec
Defines the activation delay for relay output DO1
0
Ton
1
0
1
Toff Ton Toff
Time
Status of selected
source
Delayed
DO status
 Ton: '10.27' DO1 (RN0-RN1) On delay time
 Toff: '10.28' DO1 (RN0-RN1) Off delay time
 10.28 DO1 (RN0-RN1) OFF delay time
Range: 0.0 ~ 3000 Sec in 0.1 Sec
Initial value: 0.0 Sec
Defines the activation ON delay for relay output DO1
 10.29 DO2 (RN2-RN3) source
See the parameter '10.26' (DO1 source)
 10.30 DO2 (RN2-RN3) ON delay time
See the parameter '10.27 (DO1 ON delay)
 10.31 DO2 (RN2-RN3) OFF delay time
See the parameter '10.28 (DO1 OFF delay)
 10.32 Alarm (AL0-AL1-AL2) relay source
See the parameter '10.26' (DO1 source))
 10.33 Alarm (AL0-AL1-AL2) relay ON delay time
See the parameter '10.27 (DO1 ON delay)
 10.34 Alarm (AL0-AL1-AL2) OFF delay time
See the parameter '10.28 (DO1 OFF delay)
