Chapter 4 Maintenance Procedures98
USG-CUS-059 Rev05MassARRAY® Nanodispenser RS1000 v2.1 User Guide
For Research Use Only. Not for use in diagnostic procedures.
4. Flush the calibrant reservoir with Type 1, >18.2 MΩ water.
5. Dry the calibrant reservoir with clean dry air (for example, from a compressed air can).
CAUTION
!
Do not dry the reservoir with house air which can contain oil and other contaminants.
6. Orient the calibrant reservoir as shown in Figure 4.13 and insert it into the dry station,
making sure that it is firmly seated all the way down.
7. Close the main door.
8. Tap the HOME button in the safety interlock is disengaged! message.
Wait for the pin array assembly to move to home position (all the way left, forward,
and up).
Figure 4.12 Removing the Calibrant Reservoir
Figure 4.13 Calibrant Reservoir
Lift
Dry station
Calibrant
reservoir
