Chapter 3 Methods and Mappings68
USG-CUS-059 Rev05MassARRAY® Nanodispenser RS1000 v2.1 User Guide
For Research Use Only. Not for use in diagnostic procedures.
Choose the analysis settings
•
sample tracking – Sample tracking collects information about how sample plate
wells are mapped to SpectroCHIP Array pads and automatically sends the
information to a MassARRAY Transfer Server. Sample tracking requires a barcoded
microtiter plate.
•
auto tuning – Automatically adjusts dispense speed based on Target Volume
setting. Volume check MUST be enabled in order for auto tuning to work.
•
volume check – Enables the visual volume checking feature of the instrument. After
each dispense cycle, the instrument captures images of the dispensed droplets and
estimates their volumes.
See page 39 for more information on these settings.
Specify the SpectroCHIP Array positions
Specify the positions in the SCOUT plate that contain the SpectroCHIP Arrays which will
receive sample.
Figure 3.12 Method Screen – Analysis Settings
Figure 3.13 Method Screen – SpectroCHIP Array Positions
Tap to select sample
tracking, auto tuning,
and/or volume check.
Tap each SpectroCHIP
Array position to be
used in the method.
Selected positions are
shaded in blue.
