5. Remove the waste and supply tank lids (turn them counter-clockwise) (Figure 4.27).
There will be approximately one inch of water remaining in each tank. The sensor in
the rear of the tank may be raised to allow the pumps to continue to run and drain the
remaining water.
CAUTION
!
Do not run the pumps dry as damage may occur.
6. Use clean, lint-free towels (paper or cloth) to soak up any remaining water in the
tanks.
Figure 4.26 Removing the Tank Access Panel
Figure 4.27 Removing the Tank Lids
Indicates a screw location
Tank access panel
Waste
tank lid
Supply tank lid
