Chapter 3 Methods and Mappings 85
USG-CUS-059 Rev05MassARRAY® Nanodispenser RS1000 v2.1 User Guide
For Research Use Only. Not for use in diagnostic procedures.
2. Tap additional SpectroCHIP Array pads that you want mapped to the same well.
Analyte from the plate well will be dispensed to all of the selected pads.
Saving the mapping
file
1. Tap save on the Mapping screen (Figure 3.39).
A keyboard appears. If you opened an existing mapping file, its name automatically
appears in the keyboard text box.
Figure 3.37 Mapping a Well to a Pad Using a 1-pin Array
Figure 3.38 One Plate Well Mapped to Multiple SpectroCHIP
Array Pads
First tap a
plate well
Then tap a
SpectroCHIP
Array pad(s)
Plate well A3 is
mapped to three
SpectroCHIP
Array pads
