Agena BIOSCIENCE MassARRAY Nanodispenser RS1000 User Manual

Chapter 4 Maintenance Procedures 97
USG-CUS-059 Rev05MassARRAY® Nanodispenser RS1000 v2.1 User Guide
For Research Use Only. Not for use in diagnostic procedures.
11. Close the main door.
12. Tap the HOME button in the safety interlock is disengaged! message.
Wait for the pin array assembly to move to home position (all the way left, forward,
and up).
Flush the calibrant
reservoir
Flush any calibrant from the calibrant reservoir that may remain from previous operation.
Even if calibrant will not be dispensed, flushing the calibrant reservoir is recommended to
keep it clean.
To flush the calibrant reservoir:
1. Park the pin array assembly (tap the PARK button on any screen).
Parking the pin array assembly allows easier access to the processing deck.
2. Open the main door.
The safety interlock is disengaged! message appears.
3. Remove the calibrant reservoir from the dry station by lifting it from the dry station as
shown in Figure 4.12. You may need to slightly rock the calibrant reservoir side-to-side
to lift it out.
Figure 4.11 Placing the Wash Supply Bottle on the Wash Station Block
Press
Ultrasonic wash
supply bottle
Wash station
block
Ultrasonic wash
