Chapter 3 Methods and Mappings 79
USG-CUS-059 Rev05MassARRAY® Nanodispenser RS1000 v2.1 User Guide
For Research Use Only. Not for use in diagnostic procedures.
To delete a mapping:
1. Select the Delete option (Figure 3.30).
NOTE
Mappings cannot be defined when Delete is selected. Select Add to resume mapping.
2. In the SpectroCHIP Array diagram, tap the "anchor" pad of the mapping that you want
to delete. The anchor pad is the lower left pad in the pin array footprint. If you are
working with a 1-pin array, tap the SpectroCHIP Array pad that you want to remove.
The selected SpectroCHIP Array pads are no longer mapped to the plate wells.
Figure 3.29 Defining Another Aspirate-Dispense Cycle
In this example, well E1 was the selected as the "anchor"
well (receives pin A1) in the second aspirate-dispense
cycle.
Pad B1 was selected to receive pin A1 in the second
aspirate-dispense cycle.
