2. If you opened a predefined mapping file, type a new name and tap enter.
If you opened a custom mapping file, do either of the following:
•
To save as a new mapping, type a new name and tap enter.
•
To overwrite the mapping file, keep the existing name and tap enter.
You are returned to the first mapping screen.
3. Tap exit to return to the Main Menu.
3.6 Deleting a mapping file
CAUTION
!
If you delete a mapping file that is used by a method file, the method file will no longer be available.
The mapping file specifies the pin format for a method file. When loading a method file, the
instrument shows only those method files that are appropriate for the instrument pin array format
(24, 6, or 1-pin). If the mapping file no longer exists, the instrument cannot determine the pin format
of the method file and will not display the method file.
1. Tap the BACK button on any screen and select MAPPING on the Main Menu.
(Figure 3.40).
2. Tap OPEN on the Mapping screen. The list of mapping files will appear.
Figure 3.39 Saving a Mapping File
