1. Ensure that the Enable box under Auto Tuning is checked (see Figure 2.21).
2. Enter the Target Volume in nL.
• For iPLEX and MassCLEAVE analyte, enter 12.
• For UltraSEEK analyte, enter 25.
3. Ensure that the Enable box under Volume Check is enabled.
4. Enter an upper and lower limit for dispense volume.
• For iPLEX and MassCLEAVE analyte, enter 8-20.
• For UltraSEEK analyte, enter 10-35.
NOTENOTE
Volume check must be enabled in order for auto tuning to function, and the mapping file must
include pads designated as tuning pads.
If a SpectroCHIP Array has been dispensed with auto tuning enabled, a record will be
kept of the dispense volume for each pad on the SpectroCHIP Array. See page 56 for
instructions on accessing this information for previously dispensed SpectroCHIP Arrays.
Figure 2.21 Enabling autotuning
