Agilent Cary 8454 UV-Visible Spectroscopy System Installation Guide 101
GPIB Communication, Connections and Configuration 6
Configuring the Agilent 82357 USB - GPIB Interface
14 In the Agilent Connection Expert main window select USB/GPIB
(GPIB0)
Figure 49 Agilent 82357 default settings
15 Click Change Properties.... In the Agilent 82357 Interface Converter -
USB/GPIB dialog window select or enter the following properties:
VISA interface ID: to GPIB0,
GPIB address: to 30,
SICL Interface ID: to hp82341 (note that this is case sensitive),
uncheck Auto- discover instruments connected to this interface (see
Figure 50)
Figure 50 Agilent 82357 interface configuration
