58 Agilent Cary 8454 UV-Visible Spectroscopy System Installation Guide
4 Installing Accessories
Long Path Cell Holder
Long Path Cell Holder
The Agilent 89076A long path cell holder is a sample cell holder which
can be adjusted to hold most cylindrical and rectangular sample cells with
path lengths of up to ten centimeters. It uses the same mounting system
as the other sample cell holders.
The long path cell holder includes built- in cell stops for accurate
positioning of 1, 2, 5, and 10- cm sample cells.
The optical filter wheel (08451- 60302) can be mounted on the long path
cell holder in the same way it is mounted on other cell holders, see
“Optical Filter Wheel” on page 61 for details. However, instead of a
screwdriver, a 2.5-mm hex wrench is required to install the optical filter
wheel on the long path cell holder.
Figure 17 Long path cell holder
