Chapter 5 209
Language Reference
CALCulate:LLINe Subsection
CALCulate:LLINe Subsection
Limit lines can be defined for your measurement. You can then have the instrument
compare the data to your defined limits and indicate a pass/fail condition.
NOTE Refer also to :MMEMory and :TRACe subsystems for more trace and limit line
commands.
Delete All Correction Sets in Memory
:CALCulate:LLINe:ALL:DELete
Deletes all correction sets in volatile memory.
History: Added with firmware revision A.08.00.
Front Panel
Access:
Display, Limits, Delete All Limits
Control Limit Line Amplitude Interpolation
:CALCulate:LLINe[1]|2:AMPLitude:INTerpolate:TYPE
LOGarithmic|LINear
:CALCulate:LLINe[1]|2:AMPLitude:INTerpolate:TYPE?
Selects the type of interpolation done for the amplitude values of the designated
limit line when comparing to measured data.
Factory Preset
and *RST: Not affected by preset
Remarks: Once this function is defined, the selected type is persistent.
Persistent means that it retains the setting previously selected,
even through a power cycle.
Front Panel
Access:
Display, Limits, Limit 1|2, Amptd Interp Log Lin
Set Fixed or Relative Limit Lines
:CALCulate:LLINe:CMODe FIXed|RELative
:CALCulate:LLINe:CMODe?
Specifies whether the current limit lines are fixed or relative.
NOTE If you need to change the domain with
:CALCulate:LLINe:CONTrol:DOMain, do it before this command.
Changing the domain deletes all the existing limit line values.
