Repairing the Autosampler
Stator Face
2 Loosen each fixing bolt two turns at a time.
Remove the bolts from the head.
3 Remove the stator head and stator face.
4 Place the stator face in place on the stator
head. Ensure the pins on the stator engage in
the holes in the stator head.
5 Install stator head and stator face. Tighten the
bolts alternately two turns at a time until the
stator head is secure.
