Repairing the Autosampler
Rotor Seal
6 Install the stator ring. Ensure the housing is
flush against the valve body.
7 Place the stator face in place on the stator
head.
8 Install stator head and stator face. Tighten the
bolts alternately two turns at a time until the
stator head is secure.
9 Reconnect the pump capillaries to the valve
ports (see “Hydraulic Connections” on
page 31)
10 Slide the waste tube into the waste holder in
the leak tray.
On completion of this procedure:
❏ Install the front cover.
