Repairing the Autosampler
Transport Assembly
Installing the Transport Assembly
1 Slide the transport assembly into the
autosampler.
2 Ensure the slot on the top of the transport
assembly engages with the stud on the
sampling unit.
On completion of this procedure:
❏ Ensure the transport assembly is seated firmly.
❏ Install the top cover and foam (page 128).
❏ Verify the transport assembly alignment (page 99).
Transport assembly
Sampling unit
