135
Repairing the Autosampler
Sampling Unit
2 Pull out the waste tube from the holder in the
leak tray.
3 Slide the sampling unit and tray base back to
disengage the sampling-unit connector.
4 Lift the sampling unit and tray base
approximately 10 cm. Slide the leak sensor
out of the leak plane.
5 Lift the sampling unit and tray base out of the
autosampler.
To Next Page
