138
Repairing the Autosampler
Sampling Unit
3 While holding the sampling unit and tray
base, slide the leak sensor into the holder in
the leak plane.
4 Place the sampling unit and tray base into the
autosampler.
5 Slide the sampling unit and tray base
forwards. Ensure the sampling unit
connector is seated correctly.
6 Install the pump and column thermostat
capillaries (ports 1 and 6) in the injection
valve.
Connector
To Next Page
