155
Repairing the Autosampler
Power Supply
4 Lift the power supply out of the module. 5 Remove the coupler from the of the power
supply.
6 Insert the coupler onto the switch of the new
power supply.
7 Install the power supply in the module.
8 Connect the light pipe to the coupler. 9 Install the bottom foam. Ensure the cables
are positioned as shown.
