Theory of Operation
Optional Interface Boards
The following cards can be used with the Agilent 1100 modules.
NOTE Minimum firmware of the JetDirect cards is A.05.05.
Recommended Cables
For point to point connection (not using a network hub) use a twisted pair
cross over LAN cable (P/N 5183-4649, 10 feet long).
For standard network connections using a hub use category 5 UTP cables,
(P/N G1530-61480, 8 m long).
Table 48 LAN Boards
$JLOHQW2UGHU1XPEHU 6XSSRUWHGQHWZRUNV
J4106A Ethernet/802.3, RJ-45 (10Base-T(
J4105A Token Ring/802.5, DB9, RJ-45 (10Base-T)
J4100A Fast Ethernet, Ethernet/802.3, RJ-45 (10/100Base-TX) + BNC
(10Base2)
