Introduction to the Control Module
This chapter is intended to introduce an operator to the screens available for
operation of the Agilent 1100 Series autosamplers with the Agilent 1100
Series control module.
Please use the manual of Control module for further detailed reference.
Major keys on the Agilent 1100 Control Module
NOTE The screens shown on the next pages are based on:
Control Module firmware revision B.01.01
LC Module firmware revision 3.8x
NOTE In case the control module’s display seems to be frozen (hang-up due to a
communication problem on the CAN bus), unplug the control module from
the LC module and reconnect.
ESC Return to previous screen and scroll through top layer views
(Analysis, Settings)
m Open context sensitive menus
i Information/help
Enter Store changed parameters or execute the choice from a pull-down
menu
On/Off Switch on lamp(s)
Start Start a run
Plot View the chromatogram
Views Change between view of analysis - status - system screens
To Next Page
