82
Troubleshooting and Test Functions
Change Needle
3 Remove the front cover.
NOTE Do not remove the front cover until the needle arm is in its maintenance
position. Removing the cover while the needle arm is activated may lock up
the system.
4 Exchange the needle or needle seat (see “Needle-Seat Assembly” on page 111
and “Needle Assembly” on page 108).
5 Replace the front cover.
6 Select “End” (“Done”) to complete the procedure.
