Agilent Technologies Helium Leak Detector
150
DRAFT 12
/11/17
DISABLE-xREJECT Turns the Reject Set Point OFF. Where x is a number from 1 to 4 or the
letter A.
DISABLE-RANGESTOP Turns the Range Stop function OFF.
DISABLE-VOLUME Turns audio OFF.
ENABLE-0ENABLE Turns the Zero Enable function ON.
ENABLE-PASSWORD Turns the Password feature ON.
ENABLE-xREJECT Turns the Reject Set Point ON. Where x is a number from 1 to 4 or the
letter A.
ENABLE-RANGESTOP Turns the Range Stop function ON.
ENABLE-SEQUENCER Turns the auto sequencer function ON.
ENABLE-SPLITFLOW Turns the split flow function ON.
ENABLE-VOLUME Turns audio ON.
EXTERNAL Sets the External Calibrated Leak (in test port) as the leak for use during
calibration.
INCREMENT Adds 1 to the Manual Ranging leak rate exponent (making it less negative).
Success is indicated by the normal ok response. Does nothing
in
auto-ranging mode. Does nothing upon reaching the least sensitive range.
INTERNAL Sets the Internal Calibrated Leak as the leak to be used during calibration.
KEEP Causes the leak detector to close most valves and enter the Hold state.
MANUAL Turns the Manual Ranging Mode ON. Success is indicated by the normal
ok response.
NOSNIFF Turns the HIGH PRESSURE TEST function OFF.
ROUGH Causes the leak detector to begin a roughing on the test port only.
SNIFF Turns the HIGH PRESSURE TEST mode ON.
STDLEAK Turns Read Std Leak ON/OFF. Verifies calibration by exposing internal cal
leak to the system.
TPTCATM Sets the current test port thermocouple reading to represent atmospheric
pressure when the test port is exposed to atmosphere. Success is indicated
by the normal ok response.
TPTCZERO Sets the current test port thermocouple reading to represent a ZERO
pressure reading when the test port pressure is less than 1.0E-04 Torr.
Success is indicated by the normal ok response.
Table A-4 Leak Detection Actions (Continued)
Command Action
