Page #148 background image
9-2 i3070 Series 5i Help
Parts List
Table 9- 1 Parts (Level 1)
Part Number Description Qty Category Sub-category
E9988-21201 Motor Coupling, Oldham Coupling ID15K5 and
ID19K6
1 Top Press Servo System
0490-2998 Switch-Reed 40mA 24VAC with Light indicator 2 Top Press Top Fixture Clamp
E9988-33602 TU-6 3MM ENDLESS BELT 1000MM 2 Zone 1 Conveyor Rail Assy
5186-2230 Reed Switch_24VDC/100VAC 2 Zone 1 Conveyor Rail Assy
0960-3187 Sensor Background suppression w/2m fixed
Cable
3 Zone 1 Conveyor Rail Assy
E9988-33601 TU6 3MM ENDLESS BELT L1670 2 Zone 2 Conveyor Rail Assy
5186-2230 Reed Switch_24VDC/100VAC 2 Zone 2 Conveyor Rail Assy
0960-3187 Sensor Background suppression w/2m fixed
Cable
4 Zone 2 Conveyor Rail Assy
0950-5621 Power Supply switching AC-DC 150W 1-Output 2 Electrical Panel 24VDC
0490-2999 Relay-Module 24VAC 75X110X22.5-mm 1 Electrical Panel 24VDC
0490-3000 Relay 2C 24VDC-Coil 10A 250VAC 636-Ohm
21.5X28X36-mm
2 Electrical Panel 24VDC
0490-3001 Relay 4PDT 24VDC-Coil 5A 250VAC 636-Ohm
21.5X28X36-mm
2 Electrical Panel 24VDC
0490-3002 Relay SPDT 24VDC-Coil 21.8mA 250VAC
1100-Ohm plug-in 29X13X29-mm
12 Electrical Panel 24VDC
2140-0827 Bulb 220V 10W white 3 M/C Panel Top
3131-0696 Switch-Part Pushbutton LED Lamp White 5 Interface Panel 24VDC
