Troubleshooting
i3070 Series 5i Help 6-15
Sensor Layout
Table 6- 3 lists the sensors in the system, together with their IDs and
signals to the PLC. The following figures show the locations of the sensors
in a left- to- right system. The sensor ID will be marked on labels in the
system.
Table 6- 3 Sensors
Sensor ID Signal to PLC
Zone 1 Inlet Sensor PHS-1 000
Zone 1 Stopper Sensor PHS-2 001
Zone 1 Exit Sensor PHS-3 002
Scanner Front SV11,1104 RS17, 208
Scanner Rear SV12,1105 RS18, 209
Zone 2 Guide Bar Detect Sensor PHS-19 306
Conveyor Right Limit Sensor (Dark-on) PHS-25 400
Conveyor Origin Sensor (Dark-on) PHS-24 315
Conveyor Left Limit Sensor (Dark-on) PHS-26 401
Zone 1 Stopper Up SV1,1010 RS1, 108
Zone 1 Stopper Down SV2,1011 RS2, 109
Zone 2 Inlet Sensor PHS-4 003
Zone 2 Stopper Slow Sensor PHS-5 004
Zone 2 Stopper Sensor PHS-6 005
Board Align Sensor PHS-27 402
Engine Fully In Detect Sensor PHS-9 008
Zone 2 Stopper Down SV4,1013 RS20, 211
Zone 2 Stopper Up SV3,1012 RS19, 210
Zone 2 Exit Sensor PHS-7 006
Zone 2 Clear Sensor PHS-8 007
Presser Upper Limit Sensor PHS-12 011
Presser Home Sensor PHS-14 013
Presser Clearance Limit Sensor PHS-15 014
Presser Lower Limit Sensor PHS-13 012
